Installing a dishwasher may seem daunting, but with the right instructions and a little care, it can be a rewarding DIY. And with the money you’ll save by not hiring a professional, you can afford to splurge on a high-quality appliance that will serve your household well for years. A word of wisdom, though: To keep things simple, aim to replace your current dishwasher with a model of the same or similar size. If your kitchen has never included a dishwasher before—or if the one you’ve purchased is significantly larger than your existing model—sophisticated cabinetwork may be necessary to accommodate the new machine. That’s beyond the scope of this article. But if your new appliance fits snugly into the space left by your old dishwasher, these instructions can help you install the replacement within hours.
MATERIALS AND TOOLS
- 1/2-inch flexible copper tubing
- Tubing cutter
- Tube-bending spring
- Two ½-inch compression fittings
- Adjustable wrench
- Teflon tape
- 3/8-inch to 1/2-inch brass plumbing elbow
- Hose clamp
- Plumber’s strapping
- Cable clamp
- Wire strippers
- Electrical wire nut
If your current dishwasher is still in place, the obvious first step is to remove it. Before going any further, shut off the water supply to the dishwasher and cut power to the unit. To do this, you’ll need to shut off the power at the electrical panel by toggling the switch associated with the circuit on which the dishwasher runs. Double-check that the power is truly off by trying to turn on the machine. If the dishwasher doesn’t respond, it’s safe to move on by breaking the three connections that allow the dishwasher to do its dirty work: the drain line, the water supply, and the electrical supply.
With the old dishwasher out of the way, you can now prep the connections for the new unit. While the existing electrical wiring may be reused, it’s a good idea to replace the water supply line (unless the existing supply line is copper, in which case you can skip ahead to Step 3). Remove the old, most likely braided plumbing line, and begin snaking 1/2-inch flexible copper tubing from the front of the dishwasher cabinet to the hot-water valve under the sink. Once you’re finished, use a tubing cutter to cut the line away from the remainder of the tubing coil.
Under the sink, maneuver the tubing as close as you can to the hot-water valve. To make the connection, it may be necessary to use a tube-bending spring, a small plumber’s tool that enables you to shape the tubing as needed. Secure the connection with a compression nut, which you’ll tighten with your hands before finishing off with the wrench.
Look on the bottom of the dishwasher to locate the channels along which the water supply and electrical cable are meant to run. Measure their locations with respect to the sides of the dishwasher, then transfer those measurements to the floor of the cabinet. Now use the tube-bending spring to shape the copper tubing so that it travels along the side of the cabinet and then runs along the supply line you’ve marked on the floor of the cabinet. Do the same for the electrical cable.
Your new dishwasher will have come with its own drain hose. Assuming you’ve removed the drain hose for the old dishwasher, go ahead and run the new one from the dishwasher cabinet through the existing hole and to the area under the sink. As you do so, be careful not to let any kinks interrupt the hose. In a later step, you will connect the hose to the dishwasher and the sink drain.
Enlist another person to help you ease the dishwasher onto its back. From there, you can more easily remove the panel cover at the base of the unit and access the water inlet, through which clean water will feed into the unit. Wrap Teflon tape around the threads of the inlet and use an adjustable wrench to attach either a 3/8-inch or 1/2-inch brass elbow, depending on your appliance. Now, using the tube-bending spring, turn the flexible copper supply line so that it meets the brass elbow you’ve added. Where the two meet, the copper must run for at least two inches without any bends. Secure the connection between the tubing and the elbow by placing a compression fitting over the straight run of copper. Tighten the compression nut with your hands before giving it an extra turn with an adjustable wrench.
Turn your attention to the electrical cable (which may be left over from the old dishwasher hookup). Slide a cable clamp over the exposed wires, right where the wires disappear into the plastic or metal sheathing around the wire bundle. Then locate the junction box and remove its cover plate. Loosen the nut on the cable clamp and push the wires (along with the threaded end of the clamp) through the junction box’s hole. Once you have finished, use a screwdriver to tighten the nut again on the part of the clamp that remains outside the box.
Inside the junction box, use wire nuts to join the identically colored wires, white to white and black to black. If the wires coming from your home are sheathed in plastic (such as Romex), then be sure to connect—by means of another wire nut—the green wire (the ground) to the dishwasher’s green (or bare copper) wire. Otherwise, wrap the the dishwasher’s ground wire around a mounting screw on the junction box, then fasten the screw so that the ground doesn’t budge. Finally, fold all the wires into the junction box before screwing the cover plate back onto the receptacle.
Back in Step 5, you ran the drain hose from the dishwasher cabinet to the sink drain. Now it’s time to make the necessary connections. First, slip a hose clamp over the “sink side” of the hose, then fit the hose over the inlet on the sink drain. With plumber’s strapping, secure the hose against the top of the sink cabinet (or high on its rear side), so the hose arcs before it reaches the inlet. That U-shape is very important, because it prevents sink backflow from entering the dishwasher. Meanwhile, in the dishwasher cabinet, connect the other side of the hose to the dishwasher’s drain. This latter connection should be very quick and easy to make.
With the dishwasher in place, adjust its feet until the mounting brackets meet the underside of the counter. Check with a level to make sure that the appliance isn’t tilting to either side; adjust as necessary. Now use the drill/driver to drive screws through the mounting brackets, firmly securing the dishwasher in position. Replace the access panel cover at the base of the unit, which you removed in Step 6.
Turn on the water supply and return power to the circuit to which the dishwasher is connected. Don’t turn on the dishwasher yet; over the next few hours, keep a close eye out for leaks. If there aren’t any, take your new dishwasher out for its first test run!
